Scorpio and Javelin - Offshore Cruisers

The Scorpio and Javelin use the same basic hulls as each other and as the Sagitta. LAR keels are fitted to the Scorpio and daggerboards are fitted to Javelin.

The open bridgedeck and makes Scorpio ideal for trade wind sailing. Scorpio is very dry and comfortable, with three double cabins and standing headroom together with lots of load carrying potential, see drawing below. Diesel engines and wheel steering are options

Javelin has kick up rudders (as Sagitta) and uses an outboard engine (9.9hp 4 stroke Yamaha is recommended)

Here is a short Youtube clip of a Javelin sailing one winter's day off NE England, taken from the Multihull Sailors Have More Fun! video, see the Video page for more details.

IMPORTANT NOTE

We are currently updating the Scorpio and Javelin plans so please contact us before ordering to check availability

You can see more photos, materials list etc here

http://www.sailingcatamarans.com/1scorpiojav14index.htm

To order study plans or full building plans please go to the

order form

home

Contact
Richard Woods
Foss Quay, Millbrook, Torpoint, Cornwall, PL10 1EN, UK

Scorpio and Javelin - Minimum Offshore Cruisers

THE FACTS AND FIGURES

grp kit
strip cedar hulls, ply decks

LENGTH O.A. 9.14m
LENGTH W.L. 8.55m
BEAM O.A. 5.95m
DISPL (empty) 1.8T
DISPL (loaded) 3.3T (Scorpio) 2.5T (Javelin)
HEADROOM 1.85m
DRAFT 0.8m (Scorpio) 0.5-1.5m (Javelin)
SAIL AREA 38.8 sq m (Scorpio) 50sq m (Javelin)
